081
×
![]()
Part of the Control Accessories Series
Ordering Code: 081
UPC: 779655008104
Three Outdoor Sensor Module
The Three Outdoor Sensor Module 081 includes three 10 k ohm thermistors which provides an accurate measurement of the outdoor temperature. Each sensor has two separate terminals for wiring. The 081 is designed to be installed in a tekmar Outdoor Sensor 070 enclosure. This allows for four separate sensors to be combined into a single enclosure that is mounted on the exterior of the building.
Features
- Provides outdoor temperature readings for multiple controls in one enclosure
- Each sensor has two separate terminals for wiring
- Allows for four separate sensors to be combined into a single enclosure
- Mounted on the exterior of the building
| Specifications | |
|---|---|
| Dimensions | 2-1/8" H x 9/16" W x 9/16" D (54 x 14 x 14 mm) |
| Operating Range | -60 to 140 degrees F (-51 to 60 degrees C) |
| Sensor | NTC thermistor, 10 k ohms at 77 degrees F (25 degrees C plus / minus 0.2 degrees C) Beta = 3892 |
