FBV-3C-QC
×
![]()
Discontinued - Replaced By: LFFBV-3C-QC 1/2
Part of the FBV-3C Series
Ordering Code: 0651192
UPC: 098268360301
1/2 IN 2-Piece Full Port Brass Ball Valve, Quick-Connect End
This 1/2 inch two-piece full port brass ball valve with female threaded end connections is used in residential and commercial potable water applications. The valve features brass body construction, adjustable packing gland, chrome plated brass ball, virgin PTFE seats and seals, a bottom loaded blowout proof stem, and steel handle. The temperature range is 0 to 400 degrees F (-18 to 204 degrees C). The pressure rating is 200 psi (13.8 bar) at 180 degrees F (13.8 bar at 82 degrees C).
Features
- Forged brass body construction with end adapter
- Chrome plated brass ball
- Quick-Connect inlet and outlet connections
- Can be used with copper, CPVC, PEX and PB pipe
- No thread sealants, solders or glues needed
- Can be rotated under pressure and removed and reused without using tools
- Virgin PTFE seats and seals
- Adjustable packing gland
- Bottom loaded blowout proof stem
| Specifications | |
|---|---|
| Actuation | No |
| Assembled Dry | No |
| Balance Stop Plate | No |
| Ball Material | Chrome Plated Brass |
| Body Finish | Brass |
| Body Material | Brass |
| Brand | Watts |
| Buy American Act Compliant | NO |
| Control Type | Lever Handle |
| EAN | 098268360301 |
| Electrical Rating | Does Not Apply To Product |
| GDS Status | Registered |
| Inlet Connection Size | 1/2 IN |
| Inlet Connection Size-Metric | 15 MM |
| Inlet Connection Type | Quick Connect |
| Inlet Thread Type | Does Not Apply To Product |
| Lead Free | NO |
| Maximum Temperature-Fahrenheit | 400 |
| Minimum Temperature - Celsius | -18.00 |
| Minimum Temperature-Fahrenheit | 0 |
| Outlet Connection Size | 1/2 IN |
| Outlet Connection Type | Quick Connect |
| Outlet Thread Type | Does Not Apply To Product |
| Part Number | 0651192 |
| Port Type | Full |
| Seat Material | Virgin PTFE |
| Series | FBV-3C |
| Stem Packing Material | Virgin PTFE |
| Stem Shaft Material | Brass |
| Stem Type | Bottom Loaded Blowout Proof |
| Thrust Washer Material | Virgin PTFE |
| Valve Style | 2-piece |
| WOG Rating | 200 PSI |
